Designer Radiator
JD50F
Single / Double Panel
Export-ready manufacturing
EN 442 and GOST compliant production, exporting across Europe, Russia and Central Asia since 2002.
OEM/ODM support: custom sizes, colors and packaging.
The JD50F is built on Jiuding's classic round-tube welded formula, pairing generous Φ50 vertical tubes with a Φ35 header for a timeless, full-bodied silhouette. Single- or double-panel versions cover 400–2000 W across 600 / 1200 / 1500 / 1800 mm heights. The round tube profile radiates heat in all directions for even room warmth, while the clean cylindrical lines integrate naturally into contemporary interiors. Welded from premium low-carbon steel and finished in glossy, reluster or matte powder coat — standard white, anthracite or black, custom RAL on request. CE / EN442 certified, rated to 1.0 MPa, exported to Europe, Russia and Central Asia since 2002 with OEM / ODM support.
Specifications
| Profile | Φ35 + Φ50 |
| Dimensions | 600 / 1200 / 1500 / 1800 mm |
| Heat Output (EN442 ΔT=50°) | 400–2000 W |
| Heat Output (EN442 ΔT=30°) | ≈ 206–1030 W |
| Working Pressure | 1.0 MPa (10 bar) |
| Material | Low-carbon steel |
| Available Colors | White / Anthracite / Black / Custom RAL |
| Finish | Glossy / Reluster / Matte |
