Column Radiator
JDGZ3
3-Column Steel Radiator
Export-ready manufacturing
CE/EN442-certified production, exporting to 80+ countries since 2002.
OEM/ODM support: custom sizes, colors and packaging.
The JDGZ3 three-column steel radiator features three rows of round tubes welded side by side for a greater heat surface, producing 70–160 W per section with fully adjustable output by section count, at a working pressure of 1.0 MPa. Seven height options from 300 to 1800 mm are available in White RAL 9016 or custom RAL. CE-certified to EN442, exported to 80+ countries since 2002 with OEM/ODM support.
Specifications
| Profile | 3-Column |
| Dimensions | 300 / 500 / 600 / 900 / 1200 / 1500 / 1800 mm |
| Heat Output (EN442 ΔT=50°) | Per section: 70–160 W |
| Heat Output (EN442 ΔT=30°) | Per section: ≈ 36–82 W |
| Working Pressure | 1.0 MPa (10 bar) |
| Material | Cold-rolled steel |
| Available Colors | White RAL 9016 / Custom RAL |
| Finish | Glossy / Matte |
